EOZ KNX 10.1″ KNX Touch Panel
EOZ KNX 10.1ꞌꞌ KNX Touch Panel
Model: MM310
The I-Luxus capacitive touch screen EOZ with 10.1” is build for all smart devices communication with KNX Lighting, shutters/blinds and HVAC operations, intercom, concierge services, timers, weather forecast, announcements, sensors and alarms are supported.
EOZ panel brings conveniences to your management and navigation.
Specifications:
- 10.1″ capacitive touch panel
- 6 dry contact inputs
- 3 / 6 optional Outputs for relay (Optional)
- 6 Infrared LED Outputs (Optional)
- RS 485 Output
- 1x USB HOST/OTG
- Ethernet connection (Rj45) 1 Gbit/s
- Wi-Fi 150 Mbps
- Complete data saving in case of power failure
- Android6 operating system
- Built in microphone and speakers
- Lighting, air-conditioning, heating/cooling, valves, shutter/blind, intercom, concierge services, timer, scenarios, weather forecast, security sensors, alarms, IP cameras, SIP video door phone properties
- Conformity with the CE
